Compact Size
Overall width is 1,335 mm; length is 2,710 mm. Tread measures 1,055 mm (front) and 1,000 mm (rear). Wheelbase is 1,780 mm.
Tough, rugged styling
Pickup truck style front hood, front grill and headlamp design modelled after the PRO Series MULE flagship models give the MULE SX models a tougher, rugged image like their bigger brethren.
Cargo Bed & Towing Capacity
Cargo bed dimensions are 1,040 x 905 x 245 mm. Its square, flat design makes it easy to load from three sides. Cargo bed load capacity is 181 kg
Parking Brake
Pulling the parking brake lever (conveniently located to the left of the driver’s seat) operates a mechanical internal expansion type brakefor the rear wheels.
Tilt Steering
Steering wheel has a stepless adjustability range of approximately 29o, allowing drivers to set its position to suit their preference, as well as lift it out of the way to facilitate getting in and out of the vehicle
Rugged Chassis
Highly durable ladder-type tubular steel frame designed for an ideal blend of rigidity and ride comfort.
Increased Comfort
Idealised front and rear suspension settings offer the following benefits: - increased stability - improved suspension action, contributing to off-road bump absorption and ground following, as well as increased ride comfort - improved handling response, facilitating control
Simple, Reliable Engine
The MULE SX is powered by a 401 cm3, 4-stroke, OHV, air-cooled engine. Compact, lightweight and durable, the engine is extremely reliable.
Ample Range
16-litre fuel tank gives the fuel-efficient MULEs ample operating range. Redesigned fuel tank filler hole makes refuelling much easier.
Storage
Removable front hood allows quick access to a spacious 60-litre sealed storage area. The hood releases are on the cab side, allowing access from inside the cab.
Transmission
Belt-driven automatic transmission with a Hi-Lo dual-range transfer case gives the 4WD models excellent off-road riding capability. Two forward speeds to choose from lend flexibility when hill-climbing with a heavy load.
Automotive Dashboard Design
Automotive-style dashboard designed based on that of the PRO Series models puts all controls within easy reach of the driver.
ERGO-FIT je systém rozhrania, ktorý umožňuje širokej škále jazdcov cítiť sa ako jedno telo so svojím strojom.
Motor
| Typ motora | Vzduchom chladený, štvortaktný jednovalec |
|---|---|
| Kompresný pomer | 8.6:1 |
| Ventilový rozvod | OHV, 2 ventily |
| Vŕtanie x zdvih | 82,0 x 76,0 mm |
| Zdvihový objem | 401 cm³ |
| Palivový systém | Vstrekovanie paliva |
| Mazanie | Tlakové mazanie s mokrou skriňou |
| Štartovanie | Elektrické |
| Zapaľovanie | Akumulátor a cievka (tranzistorové zapaľovanie) |
Výkon a Prevodovka
| Maximálny výkon | 9,9 kW {13 PS} / 4.000 ot./min |
|---|---|
| Maximálny krútiaci moment | 29,0 N•m {3,0 kgf•m} / 2.400 ot./min |
| Prevodovka | Variátor, automatická 2-rýchlostná so spiatočkou |
| Primárny prevdový pomer | 3.653 ~ 0.794 |
| Primárny pohon | Variator (CVT) |
| Pohon nápravy | Hriadeľ – 2WD/4WD |
| Konečný prevodový pomer | F: 3.852 (16/18 x 39/9) / R: 4.000 (64/16) |
Rám a Rozmery
| Typ rámu | Rebríkový typ, oceľové rúrky |
|---|---|
| Uhol riadenia | 9,0 ° |
| Závlek kolesa | 45 mm |
| Prepruženie kolesa – predné | 78 mm |
| Prepruženie kolesa – zadné | 79 mm |
| Pneumatika, predná | 24 x 9-10 |
| Pneumatika, zadná | 24 x 11-10 |
| D x Š x V | 2.710 x 1.335 x 1.800 mm |
| Uhol natočenia kolies Ľ/P | 43° / 38° (43° in - 38° out) - SK |
| Rázvor kolies | 1.780 mm |
| Svetlá výška | 170 mm |
| Objem palivovej nádrže | 16,0 litrov |
| Výška sedadla | 780 mm |
| Pohotovostná hmotnosť* | 468 kg |
| | *Curb mass includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). |
| Odhadovaná suchá hmotnosť** | 450 kg |
| | **Estimated Dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). |
Brzdy a Podvozok
| Parkovacia brzda | Mechanical internal expansion type on rear wheels |
|---|---|
| Typ prednej brzdy | Dvojité hydraulické Bubnové brzdy |
| Typ zadnej brzdy | Dvojité hydraulické Bubnové brzdy |
| Typ predného odpruženia | Vzpery MacPherson |
| Typ zadného odpruženia | Unit swingarm |
Príslušenstvo
Under-Seat Storage Bin
Large storage bin fits under passenger side of seat. Lift seat bottom for access. Approximately 13,5 L (3.6 gallon) volume.
•Not compatible with hard cabin
MULE SX Mirrors
Vertical shatter-resistant safety glass mirror sits in high-impact plastic housing.
Convex mirror surface increases the driver’s field of rear view. Adaptive 360° bracket rotation provides optimal viewing position.
Mirrors attach directly to vehicle ROPS.
- Sold as a set of 2
- Cannot be combined with Hard Cabin
Rear Panel
Steel with Polycarbonate Rear Panel that protects against dust, dirt, and weather. An important part of a complete cab system.
Part Number: 022CAT0092 – Rear Panel for MULE SX.
Available Modular Parts:
- 42S02U0410: Windscreen + Wiper + Washer
- 022CAT0090: Windscreen
- 022CAT0091: Roof Panel
- 022CAT0092: Rear Panel
- 022CAT0093: Door Set
- 022CAT0094: Wiper Set
- 42S02U02S03: Washer Set
Image shown is 022CAT0087A, MULE SX Hard Cabin with Sliding Windows.
Cargo Bed Liner
Made from tough 7.9,mm (5/16”) extra thick rubber, the Cargo Bed Mat protects cargo and bed surface
- Prevents cargo from sliding
- Reduces sound levels
- MULE logo in the center of mat
Bed Liner MULE SX/600/610
Slip-resistant Cargo Bed Liner for MULE SX/600/610.
Cargo Bed Liner includes divider notches to use 152mm (6") L x 51mm (2") W pieces to compartmentalize the bed.
- Matching cover for tailgate
- Slip-resistant version includes all benefits of the standard liner plus a friction-enhancing surface to help prevent cargo from sliding
- Requires drilling
Windscreen
Durable and clear windscreen made of high-quality plastic.
Part Number: 022CAT0090 – Windscreen for MULE SX.
*Does not include Wiper and Washer.
Available Modular Parts:
- 42S02U0410: Windscreen + Wiper + Washer
- 022CAT0090: Windscreen
- 022CAT0091: Roof Panel
- 022CAT0092: Rear Panel
- 022CAT0093: Door Set
- 022CAT0094: Wiper Set
- 42S02U02S03: Washer Set
Image shown is 022CAT0087A, MULE SX Hard Cabin with Sliding Windows.
Heavy Duty Rear Spring MULE SX/600/610
Heavy-Duty Reinforced Rear Coil Spring.
- Replaces standard spring, order 2 per vehicle
- Spring constant: 24.5–44.1 N
Roof Panel
Robust Steel Roof Panel that protects against rain, sun, and snow. Easy to install and adapted for the MULE SX series.
Part Number: 022CAT0091 – Steel Roof Panel for MULE SX.
Available Modular Parts:
- 42S02U0410: Windscreen + Wiper + Washer
- 022CAT0090: Windscreen
- 022CAT0091: Roof Panel
- 022CAT0092: Rear Panel
- 022CAT0093: Door Set
- 022CAT0094: Wiper Set
- 42S02U02S03: Washer Set
Image shown is 022CAT0087A, MULE SX Hard Cabin with Sliding Windows.
MULE SX Wiper Set
Provides better visibility in rainy and dirty conditions. Designed specifically for use with the MULE SX Windscreen.
- Part Number: 022CAT0094
Available Modular Parts:
- 42S02U0410: Windscreen + Wiper + Washer
- 022CAT0090: Windscreen
- 022CAT0091: Roof Panel
- 022CAT0092: Rear Panel
- 022CAT0093: Door Set
- 022CAT0094: Wiper Set
- 42S02U02S03: Washer Set
**Image shown is 022CAT0087A, MULE SX Hard Cabin with Sliding Windows.
Soft Top
Durable, weatherproof 510g (18 oz) fiber-reinforced PVC laminate material. Installs easily with durable straps. Includes fiberglass support rod to shape the peak.
- Not to be used with hard cabin windscreen
- Remove for towing or use an enclosed trailer when transporting a vehicle with a Soft Top
Half Cabin
Part Number: 022CAT0088A – Half Cabin Kit for MULE SX.
Includes: Glass windscreen, Wiper and washer kit, Steel Roof Panel, Steel with Polycarbonate (PC) Rear Panel.
Modular Parts:
- 42S02U0410: Windscreen + Wiper + Washer
- 022CAT0090: Windscreen
- 022CAT0091: Roof Panel
- 022CAT0092: Rear Panel
- 022CAT0093: Door Set
- 022CAT0094: Wiper Set
- 42S02U02S03: Washer Set
Image shown is 022CAT0087A, MULE SX Hard Cabin with Sliding Windows.
MULE SX LED Headlights with Switch
High-performance LED headlights for improved illumination and better visibility.
- Brighter and more energy-efficient than standard headlights
- Durable and long-lasting design
- Provides enhanced safety in low-light conditions
Hard Cabin
Part Number: 022CAT0087C – Hard Cabin Kit for MULE SX.
Includes: Glass Windscreen, Steel Roof, Steel with Polycarbonate (PC) Rear Panel, PC Doors with Fixed Glass Windows, and Wiper and Washer Kit.
Structure made of high-grade steel with quality black finish. The flip-up tinted single-layer safety glass windscreen features rubber seals and locks. Doors are equipped with hydraulic stoppers and automotive-style locks.
Modular Parts:
- 42S02U0410: Windscreen + Wiper + Washer
- 022CAT0090: Windscreen
- 022CAT0091: Roof Panel
- 022CAT0092: Rear Panel
- 022CAT0093: Door Set
- 022CAT0094: Wiper Set
- 42S02U02S03: Washer Set
Image shown is 022CAT0087A – MULE SX Hard Cabin with Sliding Windows. 022CAT0087C has Fixed Windows.
MULE SX Washer System
Washer System that works with the MULE SX Windscreen. Includes pump, hose, and nozzle.
Part Number: 42S02U02S03 – Washer System for MULE SX.
Available Modular Parts:
- 42S02U0410: Windscreen + Wiper + Washer
- 022CAT0090: Windscreen
- 022CAT0091: Roof Panel
- 022CAT0092: Rear Panel
- 022CAT0093: Door Set
- 022CAT0094: Wiper Set
- 42S02U02S03: Washer Set
Image shown is 022CAT0087A, MULE SX Hard Cabin with Sliding Windows.
Windscreen Kit
The perfect start to a protective cab system.
Part Number: 42S02U0410 – Windscreen Kit for MULE SX.
Includes: Windscreen, Wiper, and Washer Kit.
Modular Parts:
- 42S02U0410: Windscreen + Wiper + Washer
- 022CAT0090: Windscreen
- 022CAT0091: Roof Panel
- 022CAT0092: Rear Panel
- 022CAT0093: Door Set
- 022CAT0094: Wiper Set
- 42S02U02S03: Washer Set
Image shown is 022CAT0087A, MULE SX Hard Cabin with Sliding Windows.
MULE SX Roof & Windscreen Kit
The perfect start to a protective cab system.
Part Number: 42S02U0430– Roof & Windscreen Kit for MULE SX.
Includes: Steel Roof Panel, Windscreen, and Wiper + Washer Kit.
Modular Parts:
- 42S02U0410: Windscreen + Wiper + Washer
- 022CAT0090: Windscreen
- 022CAT0091: Roof Panel
- 022CAT0092: Rear Panel
- 022CAT0093: Door Set
- 022CAT0094: Wiper Set
- 42S02U02S03: Washer Set
Image shown is 022CAT0087A, MULE SX Hard Cabin with Sliding Windows.
The Headrest offers additional occupant comfort
- Made from high-density foam with a molded Kawasaki logo
- Sold as one individual headrest
- MULE SX No Headrest Bracket required
- Note: MULE PRO-MX models require Headrest Bracket (99994-1190)
Rearview Mirror
3D curved safety glass provides increased field of view.
- Textured black powder coating
- Cast aluminum mounting that works with 38.1mm (1 ½”) to 45mm (1 7/8”) diameter tubes
- Dimensions: 273mm (10 ¾”) L x 89mm (3 ½”)
- Fits MULE SX, MULE PRO-MX, MULE PRO-DX, MULE PRO-DXT
Can also be used in combination with the Hard Cabin for MULE PRO-MX and MULE SX.
Not compatible with the MULE PRO-DX & DXT Hard Cabin with Roof.
Rearview Mirror
3D curved safety glass provides increased field of view
- Textured black powder coating
- Cast aluminum mounting that works with 38.1mm (1 ½”) to 45mm (1 7/8”) diameter tubes
- 273mm (10 ¾”) L x 89mm (3 ½”) H
Can also be used in combination with the Hard Cabin for Mule Pro-MX and Mule SX. Unfortunately not in combination with the Mule Pro-DX & DXT hard cabin, with roof.
